Often seen on coppers or kettles in Breweries, a DIN80 or DN80 Immersion Heater is good to 20 BAR. Available with 3 or 6 looped or U bent elements with 1 or 2 stat pockets, allowing for control AND overtemp cutout if needed. With that many elements we can squeeze on a lot of power. Or if you prefer, achieve a very low watt density.
Also referred to as 3″NB.
Call Jamie on 07897 246 779 to discuss your needs.
British manufactured bespoke solutions in a coupla weeks.
The major benefit of these heaters is the ability to remove them with comparative ease. This makes them very popular with brewers & distillers, as cleaning in situ is a bugger. I know from grim experience with Alex & Nathan at Green Duck. They beat me with a big stick when I miss bits. The screams in an empty & warm vessel are blood curdling.
|3″||Flange Diameter||PCD||No. of Bolt Holes||Diameter of Bolts||Diameter of Holes||Diameter of Raised Face||Height of Raised Face|
|Table D||7 1/4″ (184mm)||5 3/4″ (146mm)||4||5/8″ (16mm)||11/16″ (17mm)|
|Table E||7 1/4″ (184mm)||5 3/4″ (146mm)||4||5/8″ (16mm)||11/16″ (17mm)|
|Table F||8″ (203mm)||6 1/2″ (165mm)||8||5/8″ (16mm)||11/16″ (17mm)|
|Table H||8″ (203mm)||6 1/2″ (165mm)||8||5/8″ (16mm)||11/16″ (17mm)||5″ (127mm)||1/16″ (2mm)|
|ANSI 125/150||7 1/2″ (191mm)||6″ (152mm)||4||5/8″ (16mm)||3/4″ (19mm)||5″ (127mm)||1/16″ (2mm)|
|ANSI 300||8 1/4″ (210mm)||6 5/6″ (168mm)||8||3/4″ (19mm)||7/8″ (22mm)||5″ (127mm)||1/16″ (2mm)|
