Over the Side Vat Heaters

Our Over the Side Vat Heaters are available in the following sheath materials.

• Stainless Steel 321 (Mild Steel Alternative) – Cheapest.
• Stainless Steel 316 – Most popular.
• Grade 1 Titanium – Only if you really need it for your specific chemical as expensive.
• PTFE/FEP/Tefl-on Sheathed elements (SS316 elements with a PTFE sheathe pulled onto them by a bloke that looks like Popeye, link for ill educated youngsters!) Only if you are rich & REALLY need it for your specific chemical as VERY expensive.
• Call Jamie on 07897 246 779 to discuss your needs.

These Over the Side Vat Heaters benefit from being moveable from vessel to vessel, (as long as you switch them off & let ’em cool down first) without the need to drain the vessel, as would be necessary with a “Thru the Side” immersion heater.

• Heavy Duty Moulded ABS Terminal Box. 3ph – 300x100x100mm, single phase 100x100x100mm.
• IP54 rated Terminal box – suitable for outdoor use,
• 12.7mm or 1/2″ elements.
• Moulded cable entry glands.
• Removeable cover for easy access to wiring.
• Adjustable moulded mounting blocks.
• Colour coded for easy identification of element sheathing material.
• Cold section markings for visual prevention of liquid level drop.
• Robust construction.
  • Single Phase
    • 3kW – 33″
    • 4kW – 36″
    • 6kW – 48″
  • 3 phase 415v
    • 6kW – 29″
    • 9kW – 33″
    • 12kW – 36″
    • 18kW – 48″
• PTFE
  • Single phase 240v
    • 2kW – 66″
    • 3Kw – 85″
  • 3 phase 415v
    • 6Kw – 66″
    • 9kW – 85″

We also stock Vat Thermostats to control temperature in your vessel.

• Incorporates high quality 30A 250V proprietary capillary thermostat.
• Standard range of 25°C to 100°C.
  • Lower ranges available on request.
• Highest quality sheathing materials provides longest possible service life.
• Removable dial and cover allows for easy access to wiring and in-house maintenance.
• IP54 rated heavy duty moulded ABS terminal boxes: –
  • 120mm x 90mm x 70mm.
  • 400mm drop into tank = X dimension.
  • Longer lengths available on request.
• Moulded cable entry glands.
• Moulded and adjustable mounting blocks.
• Colour coded for easy identification of sheathing material.

Everybodies applications & requirements are different, so best we have a conversation. Call Jamie on 07897 246 779 at your convenience. Best to come prepared with your available drop, preffered shape if it needs bending, as below, and I warn you in advance, I will tell you to confirm with your chemical suppliers as to the appropriate sheathe material & watt density for yur solution, as I know heaters, not chemicals.

Thanks for visiting.
